Distributed Antenna Systems
Single-point antenna solutions fail at scale. DAS distributes your RF coverage across an entire venue footprint: consistent signal at every seat, stage or production position.
What is a DAS?
A distributed antenna system takes a signal source (wireless mic receiver, IEM transmitter, comms base) and distributes it to multiple antennas placed strategically across a space. The result is uniform RF coverage with no hot spots or dead zones. Active DAS adds gain at each antenna point. Passive DAS uses splitters and relies on careful cable loss management.
When you need DAS
- Arena or stadium where a single antenna cannot cover 400 ft of stage
- Multi-room conference or convention center
- Theme parks and large outdoor footprints
- Theatrical with complex staging configurations
- Any show where a single omni antenna creates RF asymmetry
- Broadcast remotes where cameras roam over a large area
Active vs passive DAS
- Active DASAmplified at each node
- Best forLong runs, multiple floors
- Passive DASSplitters + LNA at head
- Best forCompact multi-zone
- HybridFiber backbone + active nodes
- Best forStadiums, mega-events
What's in the kit
- Active antenna combiners and splitters
- Helical, cardioid and omni remote antennas
- Antenna mast and stand hardware
- LMR-400 and RG8X cable bundles
- Labeled tour case packaging
- Optional RF over fiber integration
Distributed antenna deployment · Arena venue · Multi-zone UHF coverage
Rental inventory
Industry-standard wireless and RF infrastructure, system-agnostic components throughout.
| Item | Description | Qty | Status |
|---|---|---|---|
| Active Antenna Combiner/Distributor | 4-way active, 470 to 900 MHz, rack-mount, DC/PoE | 4 | In Stock |
| Helical Directional Antenna | High-gain, UHF, BNC female, 50 ohm | 8 | In Stock |
| Omni Remote Antenna | Low-profile, discreet mount, UHF | 6 | In Stock |
| Passive 2-Way Splitter | UHF, SMA, low-loss, DC-pass capable | 12 | In Stock |
| Programmable Diversity Matrix Combiner, 8-Zone | Programmable wideband diversity matrix combiner, 150 to 1160 MHz. Combines RF from eight antenna zones (four diversity pairs) on the fly via solid-state switches. Configurable as diversity 4:2, non-diversity 8:1 or 8:4. Ethernet remote control, redundant AC/DC power, programmable input attenuators, remote LNA gain control via coax. Ideal for large venues, multi-studio facilities and touring OB. | 2 | In Stock |
| Programmable Diversity Matrix Combiner, 4-Zone | Flexible wideband diversity matrix combiner, 150 to 1160 MHz, designed for multi-site production environments. Software-configurable as diversity 4:2 with 6 dB gain, or non-diversity 8:4 / 8:1. Remote antenna control, attenuation and boost management, integrated RF meter, Ethernet control. Compact form factor for touring and convention use. | 4 | In Stock |
| 16-Way Passive Splitter (Rack-Mount) | 16-way passive splitter, UHF, DC-pass, rack-mount | 2 | In Stock |
| 8-Way Passive Splitter | 8-way passive splitter, UHF, DC-pass | 4 | In Stock |
| UHF In-Line Amplifiers | UHF in-line gain stage, various gain ratings, BNC | 8 | In Stock |
| RF Adapters / Attenuators | BNC, SMA, N-type adapters; 3 dB, 6 dB, 10 dB pads | Assorted | In Stock |
| Dual-Channel UHF True Diversity Receiver (pair) | Dual-channel UHF true diversity rack receiver | 6 pr | In Stock |
| Programmable UHF Bodypack Transmitter | High-density, programmable UHF bodypack transmitter | 12 | In Stock |
| Turnkey DAS Kit, 4 Zone | Four remote antennas, four active distributors, all cable and hardware | 2 kits | In Stock |
Need a custom DAS design?
We will draft your antenna layout and coverage map before you even receive the gear.
